This article describes the DOORS DXL module operations and example programs for creating and managing DOORS modules using DXL.

Create Module in DXL

DXL allows us to create a new module using create() function. Here is an example code snippet –

// www.TheCloudStrap.Com

/************************************************************************
* $FILENAME: m1.dxl
* $DESCRIPTION: DXL Module example
*
* NOTICE: Copyright www.TheCloudStrap.Com. All rights reserved.
* Software comes without any warranties and guarantees, is provided
* as is and is not supported. Use this software at your own risk.
* Authors resume no liabilities.
*
* Contact: admin {at} TheCloudStrap.com
************************************************************************/

// Example of Module
Module m1 = null
Module m2 = null

// Creating Formal Module and Link Module
m1 = create("Sample1", "sample Formal Module description", "dxl", 1500, true) // Absolute number i.e. 1500 must be greater than 0
m2 = create("sampleLink1", "sample Link Module description", manyToMany, false)
close(m2)
print "Done!"

Here is the output –

Delete Module in DXL

The softDelete() function can be used to delete a module in DXL. Here is another example code snippet –

// www.TheCloudStrap.Com

/************************************************************************
* $FILENAME: m2.dxl
* $DESCRIPTION: DXL Module example
*
* NOTICE: Copyright www.TheCloudStrap.Com. All rights reserved.
* Software comes without any warranties and guarantees, is provided
* as is and is not supported. Use this software at your own risk.
* Authors resume no liabilities.
*
* Contact: admin {at} TheCloudStrap.com
************************************************************************/

// Example of Module
Module m1 = null
Module m2 = null

// Creating Formal Module and Link Module
// m1 = create("Sample1", "sample Formal Module description", "dxl", 1500, true)
// m2 = create("sampleLink1", "sample Link Module description", manyToMany, false)
// close(m2)
// print "Done!"

// Now delete the Module
softDelete module("Sample1")
if (isDeleted module "Sample1") {
	print "Module 'Sample1' has now softDeleted!\n"
	undelete module ("Sample1")

	if (isDeleted module "Sample1") {
		print "Module 'undelete' operation was not successful!\n"
	}
	else {
		print "Module 'Sample1' has now un-deleted!\n"
	}
}
print "Done!"

Here is the output –

Module – Open and Close

In the following example code snippet, we will see how to open a module in DXL –

// www.TheCloudStrap.Com

/************************************************************************
* $FILENAME: m3.dxl
* $DESCRIPTION: DXL Module example
*
* NOTICE: Copyright www.TheCloudStrap.Com. All rights reserved.
* Software comes without any warranties and guarantees, is provided
* as is and is not supported. Use this software at your own risk.
* Authors resume no liabilities.
*
* Contact: admin {at} TheCloudStrap.com
************************************************************************/

// Example of Module
Module m = null
current = folder("/DOORS_Training/Sample/Training")

// open module in edit mode
print "Open Module in exclusive edit mode.\n"
m = edit("Sample1", true)  // Display is set to true

print "Saving module.."
save(m)  	// save the module

print "Closing module..."
close(m)  	// close module
print "Done!"

Here is the output –

In this example, we have opened the module in exclusive edit mode with the edit() function and then closed it.

Module Status

DXL provides various built-in functions to provide the module status –

// www.TheCloudStrap.Com

/************************************************************************
* $FILENAME: m4.dxl
* $DESCRIPTION: DXL Module example
*
* NOTICE: Copyright www.TheCloudStrap.Com. All rights reserved.
* Software comes without any warranties and guarantees, is provided
* as is and is not supported. Use this software at your own risk.
* Authors resume no liabilities.
*
* Contact: admin {at} TheCloudStrap.com
************************************************************************/

// Example of Module
Module m = null
current = folder("/DOORS_Training/Sample/Training")

print "Open Module in Read mode.\n"
m = read("Sample1", true)
print "Check if module is in Read mode = " isRead(m) "\n\n"

print "Open Module in Edit mode.\n"
m = edit("Sample1", true)
print "Check if module is in Edit mode = " isEdit(m) "\n"

print "Open Module in Share mode.\n"
m = share("Sample1", true)
print "Check if module is in Share mode = " isShare(m) "\n"


print "Saving module..\n"
save(m)  	// save the module

print "Closing module...\n"
close(m)  	// close module
print "Done!"

Here is the output –

In the above example, we have shown how to check the read or edit status of a given module using dxl functions.

Module Attribute Access

The following example explains how to access module attributes

// www.TheCloudStrap.Com

/************************************************************************
* $FILENAME: m5.dxl
* $DESCRIPTION: DXL Module example
*
* NOTICE: Copyright www.TheCloudStrap.Com. All rights reserved.
* Software comes without any warranties and guarantees, is provided
* as is and is not supported. Use this software at your own risk.
* Authors resume no liabilities.
*
* Contact: admin {at} TheCloudStrap.com
************************************************************************/

// Example of Module
Module m = null
current = folder("/DOORS_Training/Sample/Training")

// open module in read mode
print "Open Module in exclusive read mode.\n"
m = read("Sample1", true)  // Display is set to true

string modName = m."Name"
string modDesc = m."Description"

print "Module Name = " modName "\n"
print "Module Description = " modDesc "\n"


print "Done!"

Here is the output –

Conclusion

In this article, we have discussed DOORS DXL Module Operation i.e. – how to create a module, delete a module, and handle different operations using DXL.
